172
Bottle Type : type 1= 50ml
type 2= 6ml
Documentation
17970/31.0.SC (electricaldiagram)
17970/31.0.PM (assembly drawing)
12.1 Maintenance
12.1.1 REPLACEMENT OF LEVEL SENSOR AND ITS FLAT CABLE
- Level Sensor Board
1. Remove the teflon tubing connected to the probe.
2. Remove the screws and the Arm cover.
3. Remove connectors JP1 (flat cable) and JP2 (mixing motor).
4. Loosen the screw holding the flat cable to the probe holder and replace the
board.
- Flat Cable
5. Remove connector JP1.
6. Cut the ribbon holding the cable (or remove the screw), loosen the GND ter-
minal, disconnect connector P2 and replace the flat cable.
All the following opera-
tions are to be made with
analyzer turned OFF.
