Parts List - Intercept
®
II with light (E27 Lamp Holders)
Part Qty Part Qty Part Qty
Hanger Bracket 1 Ceiling Canopy 1
Wall Control Assembly
comprising of wall
switch, wall knob and
capacitor
1
Bracket Mounting Screw 2 Ceiling Canopy Screws 2
Ball Joint 1 Motor Housing 1
Ball Joint Screw 1 E27 Lamp Holders 2
Ball Joint Pin 1 Blades 4
Down Rod
(26mm Diameter)
1 Blade Screws 12
Down Rod Pin Screw 1 Light Rim 1
Down Rod Short Screw 2 Diffuser (Deep dish) 1
Bracket Mounting Screw
Blade
Screw
Blade
Hanger Bracket
Ball Joint
Light Rim
Diffuser
Motor Housing
Down Rod
E27 Lamp
Holders
Installation &
User Manual
Globe
(For Illustrative
purposes only.
Lamps not Supplied)
Ball Joint Screw
Down
Rod Pin
Screw
Ceiling Canopy
Down Rod Short Screw
Ceiling Canopy
Screws
Lamps not to exceed
40W each
Wall
Control
Assembly
Ball Joint Pin
®
