5
Parts List - Intercept
®
II with CCT LED light (dimmable)
Part Qty Part Qty Part Qty
Hanger Bracket 1 Ceiling Canopy 1
Wall Control Assembly
comprising of wall
switch, wall knob and
capacitor
1
Bracket Mounting Screw 2 Ceiling Canopy Screws 2
Ball Joint 1 Motor Housing 1
Ball Joint Screw 1 LED Plastic Cover 1
Ball Joint Pin 1 Blades 4
Down Rod
(26mm Diameter)
1 Blade Screws 12
Down Rod Pin Screw 1 Light Rim 1
Down Rod Short Screw 2 Diffuser (Shallow) 1
Blade
Screw
Blade
Hanger Bracket
Ball Joint
Light Rim
Diffuser
Motor Housing
Down Rod
Installation &
User Manual
LED
Plastic
Cover
Ball Joint Screw
Down Rod Pin Screw
Ceiling Canopy
Down Rod
Short
Screw
Ceiling Canopy
Screws
Bracket Mounting Screw
Wall
Control
Assembly
Ball Joint Pin
WARNING: DO
NOT REMOVE LED
PLASTIC COVER.
ONLY QUALIFIED
ELECTRICIANS
CAN SERVICE THE
LED LAMP.
®
To Next Page
