7
Installation Instructions
(Assembling the fan)
Fig. 3
Timber
Nogging
Hanger
Bracket
Installation &
User Manual
1. Do not attempt to operate the fan (or optional light kit) with any wall control that is not approved by
HPI for use with its fans. DO NOT use solid state controllers. The use of unapproved controllers may
void your warranty.
2. Do not mix blade sets from one fan to another as this may upset the balance of the fan. If only one
blade is damaged you are still required to replace with a new set.
Ø25mm
Ø1-1/8”
Fig. 1
1
2
3
Fig. 4
Fig. 2
®
To Next Page
