8
Wiring Instructions (with and without accessory light)
WARNING: To comply with AS/NZS 60335.1 an Isolation switch must
be fitted in series with the supply of this product.
Fig. 5
Installation Instructions
(Assembling the fan)
Installation &
User Manual
1. Do not attempt to operate the fan (or optional light kit) with any wall control that is not approved by
HPI for use with its fans. DO NOT use solid state controllers. The use of unapproved controllers may
void your warranty.
2. Do not mix blade sets from one fan to another as this may upset the balance of the fan. If only one
blade is damaged you are still required to replace with a new set.
Fig. 6
1
2
3
Fig. 7
Wire colours indicative only.
Alternate colours marked with
their function.
®
To Next Page
