Installation Instructions
(Assembling the fan)
Installation &
User Manual
1. Do not attempt to operate the fan (or optional light kit) with any wall control that is not approved by
HPI for use with its fans. DO NOT use solid state controllers. The use of unapproved controllers may
void your warranty.
2. Do not mix blade sets from one fan to another as this may upset the balance of the fan. If only one
blade is damaged you are still required to replace with a new set.
Fig. 8
1
2
1
2
Direction fan will spin in REVERSE (Winter)
mode when viewed from underneath
Direction fan will spin in FWD (Summer)
mode when viewed from underneath
Fig. 9
Fig. 10
Reverse
Switch
Reverse
Switch
®
