10
42863-01 • 06/22/11 • Hunter Fan Company
5-1. Partially install two canopy screws (about 2 full turns) in the
hanger bracket.
5-2. Raise the canopy over the hanger bracket. Align partially installed
screws with key slots in canopy.
5-3. Twist canopy counterclockwise to secure.
5-4. Install third canopy screw in round hole on canopy. Securely
tighten all three screws.
Steps 5-4
Mounting Screw
Canopy
Steps 5-1– 5-3
5 • Installing the Canopy
