Hunter 28679 - Installing the Glass Bowl

13
42439-01 • 06/15/10 • Hunter Fan Company
7 • Completing Your Installation With a Bowl Light Fixture (Continued)
Installing the Glass Bowl
7-6. Install candelabra bulbs (60 Watt Maximum) into the sockets.
7-7. read the light and fan pull chains through the hole in the center
of the glass bowl. en, thread the light pull chain through the hole
in the center of the cover plate.
7-8. read the fan pull chain through the grommet hole in the side of
the cover plate.
7-9. Place the cover plate up against the glass bowl. Align the holes in
the cover plate and glass bowl.
7-10. read the light pull chain through the finial and screw the finial
onto the threaded rod end until
tight.
7-11. Attach the extra pull chains
(included) to the light and fan
pull chains using the plastic
breakaway connector. (You
may find the plastic breakaway
connector on the end of the extra
chain.)
For Light Bulbs
Metal Rod
Metal Disc
Glass Bowl
Cover Plate
Finial
Breakaway
Connector
