3 • Assembling the Top Housing
3-1. To assemble the housing to the hanger adapter, align the three
raised tabs on the hanger adapter with the three narrow notches
in the top housing. Make certain the housing sits at on the
adapter.
3-2. Install three (3) assembly screws and tighten them securely.
Steps 3-1 – 3-2
Top Housing
Assembly Screw
Hanger Adapter
