8
ACC2 STRONGBOX PEDESTAL ASSEMBLY INSTRUCTIONS
Assembly
Assembling the Hunter ACC2 inner
chassis assembly to the StrongBox
inner panel
Step 1: Install the 8-32 X 1 screws (qty: 3) in
the locations shown using #2 Phillips head
screwdriver (Fig. 1 & 2).
• Only cinch down
• Do not overtighten
Fig. 1 Fig. 2
○
○
