ACC2 STRONGBOX PEDESTAL ASSEMBLY INSTRUCTIONS
Assembly
Assembling the Hunter ACC2 inner
chassis assembly to the StrongBox
inner panel
• Orient the StrongBox inner panel as shown
with the ground stud at the bottom.
Note the three locations for installing the
screws that attach the Hunter ACC2 inner
chassis to the StrongBox inner panel.
○
○
○
○
Attachment location
Attachment location
Ground stud
Attachment location
