Air Sterilizer Maintenance
43006-01 9
NOTES:
• TheAirSterilizermustbeunpluggedduringthecleaningprocess.
• TheMainFilterwilltintotheunitONLYwhenpositionedcorrectly.TheMain
FilterhasridgesthattintogroovesintheBase.
• TheAirSterilizerwillnotoperateiftheMainFilteriseitheroutoftheunit,oris
not seated correctly in the unit.
To change the Main Filter and reset the Main Filter Life Counter:
1. Remove the used Main Filter. See Figure 7. Throw away the used Main Fil-
ter.
Fig.7-RemovingtheMainFilter
2. Install a new Main Filter. Make certain the ridges on the Main Filter line up with
the Grooves in the Base. See Figure 8.
Grooves
Ridges
Fig. 8 - Main Filter Installation
Cleaning the Pre-Filter and Changing the Main Filter (cont.)
