Hunter Bath Ventilator Fan - Page 14

Connect wiring harness.
I
C3
C4
I
Slide light mount over posts.
Attach thumbscrews.
WARNING: To reduce the risk of electrical shock,
all 3 thumbscrews MUST be properly installed.
I
J
C5
Install 2 Max 60 Watt A15 bulbs (Not Included).
C6
Screw glass dome into position.Align glass dome and push up.
K
C7
L
C8
41788-01 6/1/2005
13
