A1
D
Back out the pre-loaded screw tips until flush with the
side of the housing.
Remove the motor/blower from the housing.
Remove the wiring cover screw
.
4
Remove packing material.
A2
A3
A6
F
Loosen screw securing motor.
A4
A5
Remove the pre-loaded screw tip covers.
New Construction Installation
41788-01 6/1/2005
