Remove the wiring cover. Pop out the first wiring access slug. Use second if needed.
Insert the strain relief into the housing and secure
with the washer.
Position the correct depth mark at the bottom edge
of the joist–based on the thickness of your sheet rock.
Screw pre-loaded screws into joist or framing. Nail the tabs on both sides to joist or framing so that the
housing will be flush with the finished ceiling.
(Nails are not provided.)
5
41788-01 6/1/2005
