Reinstall the motor by inserting the tabs and pushing up into
position. Make sure the wires are not pinched
between the motor and the housing.
Secure the motor by tightening the 2 screws.
Test the motor. If the motor does not run,
check the plug connection.
Turn on the power source.
Connect 4” duct and vent to the outside. Tape joints.
to be purchased.
Connect wiring from the motor to the wiring cover plate.
41722-01 R20200515
