Hunter Type 2 Series - Assembling the Blades

12
42489-01 • 02/16/12 • Hunter Fan Company
7-1. Insert grommets into the holes in the blades.
7-2. Install one blade onto a blade iron with three blade assembly
screws.
7-3. Repeat Steps 7-1 – 7-2 untill all three blades are installed.
Step 7-1 (Detail)
Blade Assembly
Screw
Grommet
Steps 7-1 – 7-2
7 • Assembling the Blades
