15
42489-01 • 02/16/12 • Hunter Fan Company
Breakaway
Connector
8 • Completing Your Installation With a Bowl Light Fixture (Continued)
Note: In compliance with
Canadian federal energy
regulations, this ceiling
fan contains a device that
restricts its light output.
Exceeding the wattage
limit marked on the MAX
wattage sticker axed to
the light socket(s) may
result in re hazard or
improper operation.
8-10. Install light bulbs (40 Watt Maximum) into the
sockets.
8-11. Hold the glass bowl up so it ts in the shroud.
8-12. Hold the cover plate up to the bottom of the glass
bowl and secure them both by screwing the nial into
the threaded rod on the bottom of the light xture.
8-13. Attach the extra pull chains with pendants (included)
to the light and fan pull chains using the breakaway
connector. (You may nd the breakaway connector
on the end of the extra chains.)
Step 8-10
Steps 8-10 – 8-11
To Next Page
