CAUTION: e remote control device complies with part 15 of the FCC rules.
Changes or modications not expressly approved by Hunter Fan Company could void
your authority to operate this equipment.
Operation is subject to the following two conditions:
1. is device may not cause harmful interference.
2. is device must accept any interference received, including interference that may
cause undesired operation.
Note: Use with a fan that incorporates an air gap switch (normal on-o wall switch).
WARNING: Use only the Hunter Fan speed control supplied with this fan.
You must now set the jumpers in the remote transmitter and the DIP
switches in the receiver so that they match.
5-1. Change the position of the jumpers in the transmitter and the
DIP switches in the receiver. Be sure the position of the jumper in
the transmitter matches the position of the DIP switches in the
receiver. If they don’t match, the controller will not function. For
instructions on how to set the jumpers and/or DIP switches, read
the box below.
Setting Jumpers & DIP Switches
When two or more fans are located near each other, you may desire to
have the receiver/transmitter for each fan set to a dierent code, so that
the operation of one fan does not aect the operation of the other fans.
In the transmitter you can access the jumpers from the battery
compartment. e jumpers are very small. You can move them most
easily using a small pair of pliers or tweezers. IMPORTANT! Before
you change a jumper, make sure the battery is not connected to the
transmitter.
e DIP switches for the receiver are located on the at surface of the
receiver.
5-2. Install a 12-volt battery (not included) into the transmitter.
Example Jumpers & DIP Switches
Settings
Receiver 1 Receiver 2
Transmitter 2Transmitter 1
To Next Page
