8 • Assembling the Blades
Our exclusive Easy Lock™ blade assembly enables you to lock the blades
in place without tools and to remove the blades easily for cleaning.
8-1. Open the locking mechanism.
8-2. Align the holes in the blade with the blade iron.
8-3. Close the locking mechanism securely. You will feel it lock into
place.
8-4. Repeat steps 8-1 through 8-3 until all blades are installed.
Step 8-1
Step 8-3
Open
Close
