5-1. Holding the canopy, raise the fan o the hook.
5-2. Align the slots in the canopy with the tabs on the ceiling plate.
5-3. Raise the canopy over the ceiling plate. Rotate the canopy
clockwise until the tabs on the ceiling plate totally engage with
the slots in the canopy.
5-4. Partially install the three canopy screws into the canopy one at a
time. Once all three screws are in, tighten them.
5-5. Using both hands, push the canopy trim ring up to the top of the
canopy. e canopy trim ring will snap and lock into place.
Should you need to remove the canopy
trim ring, follow these steps:
1. Locate the tab indicators, small
bumps on top of tabs.
2. Press rmly on opposite sides of the
ring toward the canopy. e tabs will
ex out releasing the trim ring from
the canopy.
Step 5-2
Canopy Trim
Ring
Canopy
Ceiling Plate
Step 5-3
Steps 5-4 – 5-5
Canopy
Screw
5 • Installing the Canopy and Canopy Trim Ring
