05
3-1. How to Assemble Juicer: Assembly and Disassembly of Silicone
* Packings are consumables that are recommended
to be replaced once every 6 to 12 months. They are
available for purchase through the Customer Service
Center.
(The juice may leak if the product is not assembled
properly.)
01 Hold and take out the packing as if you are pulling
it back.
02 After cleaning, insert one side of the packing first
as if you are hooking it.
03 Insert the remaining part and press down the
perimeter.
01 Hold and take out the packing as if you are pulling it
back.
02 After cleaning, insert the packing as shown in the
figure and then press it down.
Extraction Packing
Seal Packing
01
02
⑦-3
⑦-3
01
02
⑦-4
⑦-4
Assemble the packing as shown in the figure.
Juice Cap Packing
Hopper Packing
01 Grab one side and pull it back to detach it.
02 After cleaning, check the top and bottom of the
packing and insert it as if you are hooking one side.
03 Firmly press the remaining part of the packing
without any folded area to assemble.
01
02
After cleaning, insert one side of the packing
first as if you are hooking it.
Insert the remaining part and press down the perimeter.
⑦-6
Chamber Packing
②-4
⑦-7
To Next Page
