19
Operator's Manual
26750TSC Compact Tiller
For additional information email info@ardisam.com or call 800-345-6007 M-F 8-5
REF.
NO.
PART # DESCRIPTION QT Y.
1 53617 ARM FORWARD REAR TINE 1
2 13364 FORWARD IDLER PULLEY 10MM 1
3 332033 BOLT M10 X 1.5 X 50 HHCS 1
4 W1265V0915 BOLT M8 X 25 HHCS 2
5 W1265V0904 BOLT M8 X 1.25 X 20 HHCS 2
6 18008 BUSHING 16.4MM X 22MM X 21.5MM 1
7 38397 KEY 3/16IN X 1.75IN 1
8 3235 NUT M10 X 1.5 HTPLK 1
9 803 WASHER 5/16"ID X 1-1/2"OD FLAT
16 GA.
1
10 504 LOCKWASHER-SPRING 5/16" 4
11 WF516 WASHER PLAIN 5/16 ZN 2
12 53596B YOKE ZINC PLATED CLEVIS 1
13 1416 PIN CLEVIS 1
14 1418 PIN-COTTER 1
15 18015 WELDMENT CABLE GUIDE PLATE 1
16 1407 SPRING FORWARD ARM 1
17 18043 SHIM .25 IN ENGINE MOUNT 2
18 3245 WASHER M8 8.4MM X 24MM X 2.2MM 4
19 W1200114 WASHER M8 X 1.9 SPRLK BLK OX
HIGH COLLAR
4
20 18134 BOLT M8 X 1.0 X 35 GR8.8 ZN 4
21 18036 BELT V POWER RATED 861 MM 1
22 18022 PULLEY SINGLE GROOVE 16MM ID 1
23 739 BELT GUIDE REVERSE 1
24 13276 ENGINE VIPER 99CC EPA III 1
25 18129 WELDMENT GUARD PULLEY TOP 1
26 4647 BOLT M6 X 1.0 X 18 FLANGE HH GR5
ZN F-T
3
27 W1200116 WASHER M6 X 1.5 SPRLK ZN HIGH
COLLAR
3
28 53637 BUSHING - FORWARD ARM REAR TINE 1
29 W1200126 WASHER M10 X 28 X 2.8 ZN 1
30 18104 BOLT M6 X 1.0 X 35 HH 1
ENGINE ASSEMBLY PARTS LIST
