Husky 3300113 - Service and Parts Information; Exploded View of Components; List of Replacement Parts

11
Service Parts
EXPLODED VIEW
PARTS LIST
Part Description Qty Part Description Qty
1
Screw M5x12
4
2 Regulator Knob
1
3 Bolt M4 X 12
3
Control Panel
Safety Valve
4
1
1
2
1
1
2
1
1
1
1
1
5
Pressure Gauge 6
7 Quick Coupler
1
1
1
8 Rubber Hose
9 Pressure Regulator
Capacitor Fixing Ring 01
Overload Protector 11
12 Capacitor
13 Capacitor Cover
14 Check Valve
1
1
15 Hand Grip
Air Filter 61
Transfer Tube 17
18 Elbow Fitting
19 Pump Cover
21 Thumbscrew
1
4
2
2
1
1
1
4
4
1
1
3
1
4
4
1
8
1
2
20 Self-Tapping Screw M4X17
22 Bolt M4 X 16
23 Storage Bag Bracket
24 Accessory Storage Bag
2
25 Motor Pump Assembly
26 Flange Nut M6
27
28
29
Cushion Pad
30 Plug
31
32
33
Pressure Switch
Power Cord
34
35
Bleeding Tube
36
37
Nut M5
Clamp
Drain Valve
Head Bolt M5x12
Tank Assembly
38
Rubber End Cap
Rubber Foot
