2.0 ASSEMBLY INSTRUCTIONS
(Refer to pages 3, 4, 6, and 7).
Mount wall bracket (15) using template (14). See fig.
1 and 2 on page 3.
Mount the wall bracket (15) level at a height not lower
than 1 m (3.5 ft) from the floor (fig.1).
Assemble the support arm (16) to the base (17) by
using screws supplied (18) as shown in Fig. 3.
Place the hose reel (20) under the mounting flange
(19) and assemble retaining brackets (21) using four
screws provided (22) as shown in Fig. 4.
Assemble handle (23) to lever on hose reel with the
remaining screw (24) as shown in Fig. 5.
Attach the assembled Home Storage Docking Station
TM
to the wall bracket (15) as shown in Fig. 6.
Store high pressure cleaner on the docking station as
shown in Fig.7.
