104 72 30-26 Husqvarna service manual 49
The foot control
Dismounting
Turn it upside down.
Insert a screwdriver between the sections and carefully bend the pins (A) out of their positions.
Part the sections.
Push the plug (B) of the cord device out of the potentiometer (C).
The potentiometer can now be dismounted.
Carefully bend aside the two pegs (D) holding the cord device in place and push the cord device
out of the foot control.
Mount in the reverse order.
The foot control
Dismounting
Turn it upside down.
Insert a screwdriver between the sections and carefully bend the pins (A) out of their positions.
Part the sections.
Push the plug (B) device out of the potentiometer (C).
The potentiometer can now be dismounted.
Mount in the reverse order.
