Husqvarna 966 62 87-02 User Manual

Assembly
Introduction
WARNING: Read and understand the
safety chapter before you assemble the
product.
To assemble the loop handle
1. Put the loop handle on the shaft below the arrow.
2. Install the spacer into the slot of the loop handle.
3. Install the nut and the screw. Do not tighten too
much.
4. Adjust the product to a correct work position.
5. Tighten the screw.
To assemble the J-handle
WARNING: Do not use saw blades
with the J-handle.
1. Attach the J-handle to the loop handle with the 3
screws.
2. Adjust the product to a correct work position.
3. Tighten the screws.
To install the cutting attachment guard
and the grass blade
1. Put the cutting attachment guard (A) onto the shaft
and tighten the bolt.
A
2. Turn the output shaft to align one of the holes in
the drive disc (B) with the related hole in the gear
housing.
3. Put the locking pin (C) in the hole to lock the shaft.
4. Put the grass blade (D), the support cup (E) and the
support flange (F) on the output shaft.
F
G
E
D
C
B
A
12
1999 - 001 - 14.06.2023

Husqvarna 966 62 87-02 Specifications

General

Engine Type	2-stroke
Fuel Tank Volume/Capacity	0.5 L
Shaft Type	Straight
Displacement	25.4 cm³
Line Diameter	2.4 mm
