Husqvarna DXR-310 - Mode-Specific Functions

OPERATION
Work mode
Rotate tower anticlockwise
Rotate tower clockwise
Arm 1 in
Arm 1 out
Arm 2 down
Arm 2 up
Arm 2 telescope out
Arm 2 telescope in
Arm 1 and arm 2 out
Arm 1 and arm 2 in
Arm 3 up
Arm 3 down
Angle tool inwards*
Angle tool outwards*
Adjustable fl ow to the hammer
Full fl ow to the hammer
Cutters open/close**
* The function works even if the right button on the right joystick is depressed. This can be useful if you simulta-
neously want to run arm 1 and 2 in parallel.
** The button that opens/closes the cutters varies depending on which type of cutters are being used.
English - 27
