TECHNICAL DATA
Technical data
General
Rotation speed, rpm 6
Transport speed max., km/h / mph 3/1,9
Angle of inclination, max. 30°
Hydraulic system
Volume hydraulic system, l/gal 50/13
Pump type Load sensing axial piston
pump with variable displace-
ment
Pump fl ow max.*, l/min /gal/min 65//17
Electric motor
Type Siemens 1LA9166-4LA66-Z
Power, kW 22
Speed, rpm 1455 (50 Hz)
1750 (60 Hz)
Voltage, V/frequency, Hz 380-420/50
440-480/60
Current, A 44
Control system
Control type Remote control
Signal transmission Bluetooth/cable
Weight
Without tool, kg / lb 1963/4328
Tools
Rec. max. weight, kg / lb 230/507
Dimensions
Length without tool, mm/in 2594/102
Width with track widener, mm/in 1110/44
Width without track widener, mm/in 780/31
Min. height, mm/in 1484/58
Clearance height, mm/in 185/7
Folding outrigger, mm/in 2056/81
Telescopic arm, mm/in 550/22
Caterpillar track width, mm/in 230/9
Work radius around the machine, mm/in 5200/205
*Maximum pump fl ow and system pressure cannot be taken out at the same time, the engine will be
overloaded. 60 Hz has limited displacement.
52
