Husqvarna FS 600 E - Page 28

Product dimensions
A
B
C
D
G HE F
A Height, in./mm 38.8/985 E
Min. width (blade guard is not
installed), in./mm
25.4/645
B
Min. length (pointer up and
blade guard or cutting blade is
not installed), in./mm
39.8/1010
F
Front wheel width, in./mm 12.6/320
C
Length (pointer up and blade
guard is installed), in./mm
47.6/1210 G Rear wheel width, in./mm 20.5/520
28 1620 - 003 - 28.02.2022
