Product overview, left side
9
17
8
15
13
16
12
18
14
21
1011
7
20
2
6
1
3
4
5
19
1. Light switch for working lights (light kit optional)
2. Machine stop button
3. ON button
4. Error indicator
5. OFF button
6. Water valve
7. Water tank strap
8. Water tank
9. Power plug
10. Rating plate
11. Parking brake
12. Rear wheel
13. Water inlet and water filter
14. Ground fault circuit interrupter
15. Front wheel
16. Flange cover
17. Tension screw, drive belt
18. RESET button
19. Power indicator
20. Fault indicator
21. TEST button
