KEY PART
NO. NO. DESCRIPTION
1 532 16 34-65 Battery
2 874 76 04-12 Bolt Hex Hd. 1/4-20 unc x 3/4
8 532 18 64-91 Battery Box
16 532 17 61-38 Switch Interlock
21 532 40 02-52 Harness Socket Light
22 532 00 41-52 Bulb, Light # 1156
24 532 40 02-53 Cable Battery
25 532 41 28-95 Cable Start Red
26 532 17 51-58 Fuse
27 873 51 04 00 Nut Keps Hex 1/4-20 unc
28 532 14 54-91 Cable Ground 21" Blk. 6 Ga.
29 532 40 15-45 Switch Seat
30 532 19 33-50 Switch Ign.
33 532 41 19-35 Key/Chain
34 532 11 07-12 Switch Light/Reset
40 581 02 27-01 Harness Dash/Ign.
41 817 72 04-08 Screw 1/4-20 x 1/2
42 532 13 15-63 Cover Terminal
43 532 19 25-07 Solenoid
46 532 40 17-63 Gauge Hourmeter
50 532 17 46-51 Switch PTO
55 817 06 05-12 Screw 5/16-18 x 3/4
71 532 19 42-76 Harness Chassis/Ing.
79 532 17 52-42 Socket Asm. Bulb
90 532 43 53-95 Cover Terminal Battery
91 532 19 02-70 Strap Battery
99 817 67 04-12 Screw Hex Wsh. Thdrol. 1/4-20 x 3/4
100 819 09 14-16 Washer 9/32 x 7/8 x 16 Ga.
102 532 40 44-54 Harness Pigtail Tex Ros Tuff Torq.
105 532 40 75-68 Switch Reverse
142 532 44 80-57 Harness Charge Port
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
TRACTOR - - MODEL NO. GTH264T (96041031000), PRODUCT NO. 960 41 03-10
ELECTRICAL
