10 – English
ASSEMBLY
Assembly of the handlebar
Assemble the handlebar with 2 screws on each side of the
handlebar.
Fitting the handlebar
Take care not to damage the cables and wires when you fold
up the handlebar.
Lift up the handlebar until the handlebar's upper tubular
construction comes directly opposite to the handlebar's lower
section. Tighten the knob correctly.
Assembly of the catcher
• Lift the rear deflector and insert the grass catcher
correctly so that the rear deflector locks down over the
opening in the grass catcher.
