1
7
Engine
Remove both remaining screws and
remove the engine.
9. Remove both the remaining screws
holding the engine and remove it.
NOTE!
Make sure the spacer washers
between the cutting cover and the
engine do not fall out.
NOTE!
Check the engine has the right
amount oil before starting.
To assemble, follow the instructions in the
reverse order set out for dismantling.
Tighten the centre screw to 65 Nm.
Take care when tting the blade to ensure
it is aligned correctly. The grinded edge
should go rst in the direction of rotation
(anti-clockwise viewed from below)
Loosen the zip tie and disconnect the
short-circuit cable from the terminal block.
8. Loosen the zip tie (A) holding the
short-circuit cable to the fuel hose.
Loosen the short-circuit cables (B)
and (C) on the terminal block under
the front edge of the cover.
Engine replacement
LC48, LC53
With electric starter
In addition to the procedure described
above, disconnect the terminal block
behind the engine before removing it.
Engine replacement
LC48, LC53
With electric starter
In addition to the procedure described
above, disconnect the terminal block
behind the engine before removing it.
