20 – English
Driving
Stop the engine
Preferably allow the engine to idle for a minute to obtain
normal working temperature before stopping it if it has been
working hard. Avoid idling the engine for long periods, as
there is a risk of carbon build-up on the spark plugs.
1 Lift the cutting unit with the hydraulic lifting lever.
The unit can then be secured in the raised position if
necessary by moving the mechanical lifting lever
backwards to the lock position.
If the cutting unit is left in the lower position, the start lock
circuit will prevent engine starts.
2 Move the throttle control to the MIN. position. Turn the
ignition key to the ”STOP”.
3 When the Rider is at a standstill, press down the parking
brake and push in the locking button.
2
1
