ASSEMBLY

DESCRIPTION)

ASSEMBLY OF GRASS CATCHER

OPERATION

ENGINE ADJUSTMENTS

Refer to the engine manufacturer's maintenance manual.

CAUTION:- 0.6l Oil must be added to the engine before use.

ASSEMBLY

ADJUSTMENT OF CUTTING HEIGHT

 Always operate with the deflector or grasscatcher in the correct position.

 Always stop the engine before removing the grasscatcher or adjusting the height of cut.

 Never place your hands or feet underneath the deck or into the rear grass discharge chute while the engine is running.

Before mowing, remove all foreign objects from the lawn which may be thrown by the machine. While mowing, stay alert for any foreign objects which may have been

missed.

Never lift the rear of the mower while starting the engine or during normal operation.

Never place your hands or feet underneath the deck or into the rear discharge chute while the engine is running.

SAFETY PRECAUTIONS

ENGLAND

1 Upper handles 7 Deck 14 Engine stop lever

2 Fuel-enrichment pump 8 Adjusting levers for cutting height 15 Reduction gear

3 Fastening knobs for upper handles 9 Spark plug 16 Console

4 Grass catcher 10 Fuel cap 17 Clutch lever

5 Oil filler cap 11 Engine start-grip 18 Blade engagement lever

6 Oil drain plug 12 Rear deflector 19 Handle advance speed

13 Throttle lever

STARTING THE ENGINE

Once the machine has been set up properly, start the engine as follows:

a) Engines with choke system:

when the engine is cold, position the accelerator lever (13) on START

b)Operate the engine stop lever (14) to prepare the engine for start, keep lever pressed against handle while starting and using the machine - it operates the engine

brake.

c) Engines with primer system:

Press the fuel-enrichment pump (2) located on the carburettor 3 or 4 times position the accelerator lever (13) on MAX.

For further information and explanations, read carefully the user instruction manual of the engine.

d) Start engine.

MANUAL STARTING: (While holding the engine stop lever (14)).

Hold the engine start-grip (11) and pull the starter rope gently until you feel the resistance caused by compression. Return the starter rope slowly then pull the handle

firmly towards you to its full extent.

Self-Propelled Lawnmower.

Remove the bail arms, attach cables as shown and re-fit the bail arms.

3 Speed Self-Propelled Lawnmower.

Remove the bail arms, attach cables as shown and re-fit the bail arms.

3 Speed Self-Propelled Lawnmower with Blade Brake.

Remove the bail arms, attach cables as shown and re-fit the bail arms.

MULCHING CAP INSERTION)

To cut the grass with the mulching system (no grass collection), lift the rear deflector panel and insert the cap by fixing it with the spring as shown in the figure.

ADJUSTMENT OF HANDLES HEIGHT
