Husqvarna R 422Ts User Manual

English – 3
Ser vice journal
Pre-deliver y service
1 Charge the battery for 4 hours at max. 3 amp.
2 Fit steering wheel, seat and any optional
equipment.
3 Check and adjust tyre pressure. (60 kPa, 0.6 bar,
9 psi).
4 Adjust cutting unit:
Adjust lift springs (effective weight of cutting unit
should be 12-15kg / 26.5-33 lb).
Adjust cutting unit so that rear edge is about 2-4
mm / 1/8” higher than front edge.
Adjust the cutting unit’s cutting height setting so
that the connection rod is tensed at the lowest
cutting height.
5 Check that the right amount of oil is in the engine.
6 Check that there is oil in the transmission’s oil
tank.
7 Connect battery.
8 Fill with fuel and start engine.
9 Check that machine does not move in neutral.
10 Check:
Forward drive.
Reverse drive.
Operation of blades.
Seat safety switch.
Lif lever safety switch.
The safety switch for the hydrostat pedals.
11 Tell customer about:
Needs and benefits of following the service
schedule.
Servicing and the influence of this journal on the
second-hand value of the machine.
The transmission guarantee is only valid if the
synchronisation of the front and rear wheels has
been checked and adjusted in compliance with
the service schedule. The system will be damaged if
synchronisation is not carried out.
Range of applications for BioClip.
Complete proof of sale etc.
Pre-delivery service carried out. No outstanding problems.
Certified:
________________________________________________
Date, mileage, stamp, signature
After the fi rst 8 hours
1 Change engine oil
2 Changing the gearbox oil (Only AWD-machines)

Husqvarna R 422Ts Specifications

General

Cylinders	2
Oil Filter	Yes
Battery Type	Lead-Acid
Battery Voltage	12 V
Cutting Deck Material	Steel
Blades	3
Powder-Coated Cutting Deck	Yes
Transmission Type	Hydrostatic
Seat Material	Vinyl
Service Reminder	Yes
Cup Holder	Yes
Headlights	Yes
Sound Power Level, guaranteed (LWA)	100 dB(A)
Power Output	14.5 kW
Engine Cooling	Air
Fuel Type	Gasoline
Cutting Width	107 cm
Cutting Methods	Rear Ejection
Blade Engagement	Electric
Tyre Dimension Front	15 x 6.0-6
Wheel Size (Front)	15 inches
Wheel Size (Rear)	18 inch
Seat Type	High-back
Hour Meter Type	Digital
Parking Brake, type	Mechanical
Cylinder Displacement	656 cm³
Cutting Height, min-max	25-102 mm (1-4 inches)
