Husqvarna SMR 450-R User Manual

J.1
Part. N. 8000 B0148 (02-2008)
REAR SUSPENSION
Section
J
Rear suspension ....................................................... J.3
Removal of rear shock absorber ............................... J.4
Disassembly, overhauling and reassembly
of the rear shock absorber ....................................... J.5
Overhaul the spring................................................... J.5
Checking the shock absorber .................................... J.5
Removing the reservoir plug and the valve................ J.6
Checks on the piston unit .......................................... J.8
Replacing the gasket ................................................ J.8
Checking the adjustment ......................................... J.9
Reservoir replacement .............................................. J.10
Disassembling the air/oil diaphragm of the reservoir .. J.11
Reassembling the shock absorber ............................ J.11
Shock absorber damping adjustment ...................... J.14
Disassembly and overhauling the rear swing arm ..... J.15
Overhauling the rear swing arm axle ......................... J.16
Overhauling the rocking lever and
the rear suspension tie rod ........................................ J.16
Chain tension rollers, chain driving roller,
chain guide, chain runner ......................................... J.17
