34
TRACTOR - - MODEL NUMBER YTH20F42T (96043003900), PRODUCT NO. 960 43 00-39
ENGINE
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
For engine service and replacement parts, call the toll free
number for your engine manufacturer listed below:
Kohler Co. 1-800-544-2444
1 - - - - - - Engine Kohler Model No. SV600
2 532 18 86-65 Muffler
9 532 19 43-20 Keeper Belt Engine
11 532 18 05-05 Clutch
12 532 40 50-97 Pulley Engine
15 532 40 00-21 Tank Fuel
18 532 19 42-67 Cap Asm
20 532 40 15-08 Control Throttle
21 817 72 04-08 Screw 1/4 - 20 x 1/2
28 532 40 11-35 Fuel Line
29 532 13 71-80 Spark Arrester Kit
31 532 14 50-06 Clip Push-in Hinged
37 532 12 34-87 Clamp Hose
41 532 12 61-97 Washer 1-1/2 OD x 15/32 ID x .250
42 810 04 07-00 Washer Lock 7/16
45 873 51 04-00 Nut Keps Hex 1/4-20 unc
69 532 18 59-09 Gasket
79 532 19 23-34 Screw Socket HD 5/16-18 x .75
81 532 14 84-56 Tube Drain Oil Easy
82 532 18 16-54 Plug Drain Oil
85 532 17 39-37 Bolt Hex 7/16-20 x 4 x Gr. 5-1.5 Thr
87 537 17 18-77 Bolt 5/16-18 UNC x 3/4 w/Sems
90 817 00 06-16 Screw 3/8-16 x 1
91 532 18 74-95 Bushing 1.375 OD
92 817 12 06-16 Screw 3/8-16 x 1
94 532 18 86-54 Tube Exhaust
KEY PART
NO. NO. DESCRIPTION
1
29
SPARK ARRESTER KIT
92
45
21
20
engine-tex_kohl_5
81
82
94
69
87
2
18
15
37
28
37
12
11
85
41
42
90
9
31
79
91
To Next Page
