REPAIR PARTS
TRACTOR - MODEL NO. YTH2448 (96015000103), PRODUCT NO. 960 15 00-01
CHASSIS AND ENCLOSURES
KEY PART
NO. NO. DESCRIPTION
1 532 1746-19
2 532 17 65-54
9 532 19 61-38
10 872 14 06-08
11 532 17 49-96
13 532 18 17-19
14 817 49 06-08
17 532 18 99-77
26 873 80 06-00
28 532 18 82-69
30 532 19 48-06
31 532 13 99-76
37 817 49 05-08
38 532 17 57-10
39 532 17 47-t4
53 532 18 83-73
55 532 18 83-72
58 532 18 93-52
60 872 14 06-06
64 532 17 49-97
74 873 68 06-00
90 532 12 43-46
142 532 17 57-02
143 532 18 66-89
144 532 17 55-82
145 532 15 65-24
158 532 16 20-37
159 532 19 24-04
208 817 67 06-08
209 817 0006-12
212 532 18 82-67
213 532 18 99-79
214 532 18 99-78
217 532 18 54-36
258 532 18 99-81
259 532 18 99-82
276 532 18 92-74
277 532 18 92-75
278 532 19 16-tl
280 817 06 06-16
Chassis Stamping
Drawbar
Dash P/L M
Bolt Carriage 3/8-16 x 1
Panel Dash Lh
Panel Dash Rh
Screw Thdrol 3/8-16 x 1/2
Hood
Nut Lock Hex W/Ins 3/8-16 unc
Grille/Lens Asm.
(Includes Key #'s 212,258,259)
Fender Footrest STLT Pnt
Bracket Support Fender
Screw Thdrol 5/16-18 x 1/2 TYT
Bracket Asm Pivot Mower Rear
Bracket Pivot
Bracket Dash LH
Bracket Dash RH
Air Duct Engine
Bolt Rdhd Sqnk 3/8-16 unc x 3/4
Dash Lower STLT
Nut Crownlock 3/8-t6 unc
Nut Self-thd Wsh-Hd 1/4
Plate Reinforcement STLT
Bracket Swaybar Chassis
Bracket Pnt Footrest STLT
Rod Pivot Chassis/Hood
Bracket Parking Brake
Cupholder
Screw Thdrol 3/8-t6 x 1/2 TYT BI
Screw 3/8-16 x 3/4
Insert Lens Reflect
Skirt Side LH
Skirt Side RH
Console Fuel Window
Lens RH
Lens LH
Bumper Hood RH
Bumper Hood LH
Screw 10 x 3/4 Single Lead Hex
Screw 3/18-16 x 1
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
33
To Next Page
