Husqvarna YTH24V48LS - Mower Lift

41
TRACTOR - MODEL NO. YTH24V48LS (96043009800), PRODUCT NO. 960 43 00-98
MOWER LIFT













LIFTTEX?





2 532 42 20-27 Shaft Asm., Lift
3 532 19 52-30 Lever Asm., Lift RH
7 532 41 15-55 Grip, Lever
10 532 19 63-14 Spring Torsion
41 532 17 59-94 Nut Lift Link 7/16-20
87 532 19 42-09 Pin Cotter 7/16 Bow Tie Lock
88 532 41 07-10 Spring Lift Assist
89 819 19 19-12 Washer Clear Zinc
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
91 532 19 51-81 Link Lift Susp Mower Rear
96 532 19 52-63 Bushing Spherical
97 817 00 06-12 Screw 3/8-16 x 3/4
98 574 82 25-01 Link Asm. Susp. Front Mower
114 873 36 07-00 Nut Jam 7/16-20
KEY PART
NO. NO. DESCRIPTION
