Hussmann RL - Apply Gaskets to Right End

7
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
P/N 0387177_K
Figure 5A, Part 2. Apply Gaskets to Right End of RL/RM/RMF and RLN/RMN
RL / RM /
RMF
and
RLN / RMN
notes:
1. The perimeter gasket, Item 3,
is required by NSF.
2. Butyl is NOT an acceptable
substitute for donut or foam
gasket.
F
R
O
N
T
Right End
Left End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x
in
3- in x in
Use all three gaskets
When applying an end
assembly.
2
3
Apply Pad Shoe Sealer first,
then apply the narrower Foam
Tape Gasket — 3 around
the perimeter of the right end
frame outside of the donut
gasket as shown in Figure 5A,
Part 2, 5B or 5C, Part 2.
• Lap gaskets at lower
corners.
• Check that there are no
gaps between gasket and case.
• Do not stretch gasket,
especially around corners.
To make sharp corners,paper
backing can be torn without
removing from gasket.
• Do not butt gaskets; always
lap joints.
• Remove paper backing after
gasket is applied to keep gasket
free of debris.
• Gasket has high tack
adhesive and must be properly
placed the first time.
Right End Case
1
Overlap
Gasket
Pad Shoe
Sealer
F
R
O
N
T
Right End
Left End
F
R
O
N
T
PadShoeSealer
1- Donut
2- 1 in x
in
3- in x in
Use all three gaskets
When applying an end
assembly.
ALL MODELS: Apply
gasket between
wipes.
