Hussmann SMGT - Electrical Data and Wiring Diagrams; Electrical Data Tables

SMGT Data Sheet
Impact SMGT
Meat / Delicatessen
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
Electrical Data
Number of Fans 4 ft 6 ft 8 ft 12 ft
Refrigeration (120V 60hz) – 4W 1 2 2 3
Ambient Air Wipe – 15W 2 4 4 6
Export Refrigeration (230V 50 hz ) – 4W 1 2 2 3
Export Ambient Air Wipe – 15W 2 4 4 6
Amperes Watts
Merchandiser 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
Refrigeration Fans
Standard (120V 60hz) 0.31 0.62 0.62 0.93 24 48 48 72
Energy Efficient(120V 60hz) NA NA NA NA NA NA NA NA
Export: 230V 50 hz 0.18 0.36 0.36 0.54 27 54 54 81
Ambient Air Wipe Fans
Standard (120V 60hz) 0.26 0.52 0.52 0.78 15 30 30 45
Energy Efficient(120V 60hz) NA NA NA NA NA NA NA NA
Export: 230V 50 hz 0.13 0.26 0.26 0.39 15 30 30 45
Constant On Anti-sweat Heaters NA NA NA NA NA NA NA NA
Cycling Anti-sweat Heaters NA NA NA NA NA NA NA NA
Minimum Circuit Ampacity
With Standard Fans (120V 60hz) 0.77 1.34 1.34 1.91
With Energy Efficient Fans (120V 60hz) NA NA NA NA
With Export Fans (230V 50 hz ) 0.51 0.82 0.82 1.13
Maximum Over Circuit Protection 120V 20 20 20 20
Electric Defrost Heaters (208V) NA NA NA NA NA NA NA NA
Gas Defrost Heaters (208V) NA NA NA NA NA NA NA NA
Standard Lighting* (120V 60hz) 4 ft 6 ft 8 ft 12 ft 4 ft 6 ft 8 ft 12 ft
2 Row Canopy 0.49 0.80 0.98 1.42 58 92 116 170
1 Row Rail 0.49 0.40 0.49 0.71 58 46 58 85
Optional Lighting
1 Row Ledge 0.49 0.40 0.49 0.71 58 46 58 85
2 Row Shelves 0.49 0.80 0.98 1.42 58 92 116 170
*230V lighting values are under review.
