Hussmann SMGT - Fan Wiring; Electric Service Receptacle

5 of 6
P/N 0420064A
R = Red G = Green BL = Blue LB = Light Blue DB = Dark Blue B = Black W = White
= 120V P
OWER = 120V NEUTRAL = Field GROUND
= Case GROUND
Fan Wiring
Offtime Defrost
Fans
Electric Service Receptacle
Receptacles
120V N EUTRAL
MAROON
BAND
120V P OWER
W
B
G
N.E.C.
TAGS
MAROON
BAND
Refrigeration
Thermostat
To
Condensing Unit
}
(Field Installed)
3
BROWN BAND
Fans
BROWN BAND
120V POWER
120V NEUTRAL
WARNING
All components must have mechanical ground, and the merchandiser must be grounded.
Circled Numbers = Parts List Item Numbers
Grayed components in 12 foot models only.
1
BROWN BAND
Fans
BROWN BAND
120V POWER
120V NEUTRAL
2
Ambient Fan
Wiring
Glass Air Wipe
Fans
LB
LB
4 ft case has 1 Fans
6 ft case has 2 Fans
8 ft case has 2 Fans
12 ft case has 3 Fans
4 ft case has 2 Fans
6 ft case has 4 Fans
8 ft case has 4 Fans
12 ft case has 6 Fans
HUSSMANN CORPORATION, Bridgeton, MO 63044-2483 U.S.A.
