Hussmann VRL - Right View

HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
VRL Merchandisers
PN_3155541_E 29
REMOVE ACCESS
PANEL, LIFT AND
PULL OFF
ELECTRICAL BOX
LOCATED ON THE RIGHT
SIDE OF THE CASE
RIGHT VIEW
SUPPORT ELECTRICAL
BOX FIXED ON RIGHT
SIDE OF THE CASE
SLIDE ELECTRICAL BOX TO
FRONT OF THE CASE
UNSCREW COVER TO
ACCESS COMPONENTS
REMOVE ACCESS
PANEL, LIFT AND
PULL OFF
ELECTRICAL BOX
LOCATED ON THE RIGHT
SIDE OF THE CASE
RIGHT VIEW
SUPPORT ELECTRICAL
BOX FIXED ON RIGHT
SIDE OF THE CASE
SLIDE ELECTRICAL BOX TO
FRONT OF THE CASE
UNSCREW COVER TO
ACCESS COMPONENTS
CONTROL BOX VRL1B1A
The control box is located in the machine
compartment. The control box contains
electrical components such as the controller
board, relays, etc. See data sheet for additional
details on the wiring diagram.
