2 Operation
2 - 5
upon each pressing of “Start” key.
8. Node Skip: This function can be selected at all times whether under running or
stopping status.
On Auxiliary Panel, press “Node Skip” key to select or cancel such function.
When “Node Skip” indicator is on, it means such function is active; otherwise, it
will be cancelled. When hitting “/1” Node during the execution after selecting this
function, it will skip and will not execute such node.
9. W orking Quantity and Time Indication (as per Fig. 2-3):
(1) Set Count: Set the limit value of the working count (to set under Parameter
screen). When set value equals to 0, the maximum value of the working count
will be limitless.
(2) Working Count: When running to M15, an increment of “1” will be added. If
manual reset is required, under Auto Display screen, quickly press “0” Key
for twice and it will be reset to zero. Further, the user can also run “M16
Command” to clear the working count.
(3) The program will stop automatically when the working count reaches the Set
Count, therefore M15 Command should be located at the rearmost end of the
working process. Upon reaching the working count, the screen will indicate
the working count up message. At this time, the customer can restart the
program using the Reset key or pressing the Start key directly to restart the
program and reset the worked count to zero.
(4) Working Time: Display the duration (second) of the program currently
executed. When restarting the program after the program is interrupted or
ended, it will reset to zero automatically.
(5) Calendar: As per Fig. 2-3, the figures displayed under the “Working Time”
represent the current time. The time can be set under “Software Version”
screen.
10. W orking Route Drafting: Under Auto Mode or Program Est. Mode, the customer
can access the drafting screen by pressing the “Draft” key to observe the working
route, as per Fig. 2-6.
(1) Display Percentage: With Page Up/Page Down page key, you may adjust the
displayed percentage of the working route flexibly in dynamic way.
(2) Display Position: With Up/Down/Left/Right Direction Cursor key, you may
adjust the graphical Home Position displayed in the screen or adjust the draft
Home Position by letter keys in a quicker manner.
I-Screen Upper Left; J-Screen Middle Up; K-Screen Upper Right
