HUST CNC H6D-T User Manual

2 Operation
2 - 17
the screen will display the active Spindle.)
8. Corresponding Coordinate Zero Setting: Under “Manual” screen, press “F6”, “F7”
and “F8” keys and you may set the corresponding X, Y (staring status) and Z
coordinates at zero.
9. Manual Switch:
a. Spindle: CW, CCW, Stop
b. Coolant: Press once for ON and press again for OFF.
c. Manual Chuck: Press once for releasing and press again for clamping.
d. Tool Change: For Hydraulic Turret and Electric Turret, press “Manual Tool
Change” key and you may change to next tool along the direction set in the
“Manual Tool Change Direction” parameter item.
e. Chip Remover: Press “Chip Remove CW” and “Chip Remove CCW”, and
you may change the status of Chip Remover flexibly.
f. Tailstock FWD/REV: Press “Tailstock FWD” and “Tailstock REV” key, and
you may control the Tailstock action manually.
* MPG Mode Screen
MODE switch turn to MPGx1 MPGx10 MPGx100 :
Fig.2-18
Press “Jog” key and you may select the axis (the selected axis will indicate reverse
white on the screen), and then rotate the Hand Wheel to move the axis. You may also
select the multiple of Hand Wheel by adjusting the knob position, such as 1x, 10x and
100x.
