608269CE 7-1 REV A
CZ
DA
DE
EN
ES
FR
IT
NL
PT
SV
TECHNICAL SPECIFICATIONS
Hustler
®
Dash™ XD
Guaranteed
Sound Power
Level Operator Ear * Engine RPM
** Vibration (Maximum
weighted acceleration
m/s2 - whole body) Machine Mass
Nominal
Engine Power Cutting Width
Model No. dBA dBA RPM m/s2 kg kW cm
940742CE 100 87.3 2500 (± 50) 0.49 197 10.4 86
940759CE 100 87.3 2650 (± 50) 0.59 209 11.0 107
940767CE 105 91.4 3050 (± 50) 0.88 220 12.8 122
Sound
Measurements
(dBA)
Sound Power per Hemisphere method (ISO 3744 - 1994 & 11094 - 1991)
* IMPORTANT: Never alter or tamper with the engine speed (RPM) settings.
* Whole Body
The acceleration value depends upon the roughness of the ground, the speed at which the mower is operating and the
operator driving habits. Measurements were obtained through actual field data according to STD Procedure in ISO 2631-
1-1997.
Hand/Arm These values were obtained through hand/arm measure per ISO 5349-1-2001.
Model No.
940742CE The RMS acceleration in m/s² measured in 24 seconds is less than 3.53 m/s².
940759CE The RMS acceleration in m/s² measured in 24 seconds is less than 3.14 m/s².
940767CE The RMS acceleration in m/s² measured in 24 seconds is less than 4.41 m/s².
Test was performed on a static (stationary) machine.
