Élément Numéro de pièce Qté Nom
37 059832 6 NT #10-24 HX NL ZN
38 077842 2 MS#6-32X1.000RDSL
39 314351 1 ARM W/A, WB DAMPER
40 607685 1 CS .250-28X 0.625 SH
41 781922 2 BALL STUD
42 788349 1 DAMPER, CENTERING
43 607502 2 BUSHING
44 607503 2 SLEEVE BEARING
45 601798 1 BRAKE ROD ASSY, CONSOLE
46 607569 1 WIRE HARNESS
47 785808 1 KEY ASSEMBLY
48 776476 1 SWITCH, PTO 6201-321
49 769166 1 HOUR METER
50 712257 1 INDICATOR LIGHT, RED(FS)
51 045898 1 IGNITION SWITCH
52 786657 1 CABLE, CHOKE
53 767954 12 FW 0.379X.82X.06 HD ZN
54 055822 4 CS .375-16X0.75 HX G5 ZN
55 601094 1 CABLE, THROTTLE
56 125471-1 1 TOWER, W/A
57 000331 4 WIRE TIE, SMALL/SHORT
58 601053 2 RELAY, SEALED W/BRACKET
59 114052 1 KIT, CLUTCH CONN. REP.
Instrument Panel (Multi-Page)
48" TrimStar Parts Manual - 939504CE - HTTSRS048KAWFS600VC
Thu May 28 06:43:22 UTC 2020 4-3
