Comments for Page: Deck, Deck Belt & Blades
1. Torque to 160 N•m.
2. Do not torque; the discharge chute must pivot freely.
3. Torque to 1.7 N•m.
4. Torque to 4–8 N•m.
Élément Numéro de pièce Qté Nom
1 068551 4 NT .250-20 HXZY NL
2 768515 4 FW 0.281SAE
3 553531 2 SVC PULLEY COVER,
4 602562 2 DECAL, NO SERVICE
5 605469 1 DISCHARGE CHUTE
6 602435 1 SPRING, TORSION
7 086660 1 NT .375-16NLG8
8 602432 1 PIN, CHUTE
9 601969 1 DECK BELT
10 604658 2 PIN, PULLER
11 116336 2 PUSHER W/A
12 017301 2 HP .125 X2.375 ZN
13 781567 3 NT .500-13NLG5
14 767962 3 FW .531 x 1.063 x .175
15 602341 1 WHEEL, ANTI-SCALP
16 602344 1 SPACER, ANTI- SCALP 5.73
17 602338 1 CB .50-13 X 7.50 STD ZN
18 604780 2 WHEEL, ANTI-SCALP
19 602339 2 CB .50-13 X 4.50 STD ZN
20 016253 2 CB .312-18X .750 FUL ZN
21 605376 1 DECK BUMPER
22 079210 2 FW 0.344X1.0X0.06 ZN
23 604251 2 NT .312-18 HXNL JAM G2ZN
24 606252 3 BLADE, 16.5"-H-F-CW
Not Shown 795757 3 BLADE, F16.50"-H-F-CW
Not Shown 601014 3 BLADE, F16.50"-L-F-CW
Not Shown 601123 3 BLADE, 16.50"-L-F-CW
25 782474 3 CW .678 X 2.250 X .187
26 781872 3 CS .625-11X1.250HXG5
Deck, Deck Belt & Blades
48" TrimStar Parts Manual - 939504CE - HTTSRS048KAWFS600VC
Thu May 28 06:43:33 UTC 2020 7-4
